What Timeouts Should I Use In Mail Server To Get Email Through Traffic Control?

As our customer base grows, we are increasingly coming into contact with email marketers who want to know how they should configure their outbound mail servers in such a way that they can still deliver email across a traffic shaped connection. I thought it would be useful to put together a brief post instructing ESPs on the SMTP timeouts, which Traffic Control is designed to respect so that all legitimate senders have a chance to get their email delivered.

4.5.3.2.  Timeouts
  An SMTP client MUST provide a timeout mechanism.  It MUST use per-
  command timeouts rather than somehow trying to time the entire mail
  transaction.  Timeouts SHOULD be easily reconfigurable, preferably
  without recompiling the SMTP code.  To implement this, a timer is set
  for each SMTP command and for each buffer of the data transfer.  The
  latter means that the overall timeout is inherently proportional to
  the size of the message.
  Based on extensive experience with busy mail-relay hosts, the minimum
  per-command timeout values SHOULD be as follows:
4.5.3.2.1.  Initial 220 Message: 5 Minutes
  An SMTP client process needs to distinguish between a failed TCP
  connection and a delay in receiving the initial 220 greeting message.
  Many SMTP servers accept a TCP connection but delay delivery of the
  220 message until their system load permits more mail to be
  processed.
4.5.3.2.2.  MAIL Command: 5 Minutes
4.5.3.2.3.  RCPT Command: 5 Minutes
  A longer timeout is required if processing of mailing lists and
  aliases is not deferred until after the message was accepted.
4.5.3.2.4.  DATA Initiation: 2 Minutes
  This is while awaiting the "354 Start Input" reply to a DATA command.
4.5.3.2.5.  Data Block: 3 Minutes
  This is while awaiting the completion of each TCP SEND call
  transmitting a chunk of data.
4.5.3.2.6.  DATA Termination: 10 Minutes.
  This is while awaiting the "250 OK" reply.  When the receiver gets
  the final period terminating the message data, it typically performs
  processing to deliver the message to a user mailbox.  A spurious
  timeout at this point would be very wasteful and would typically
  result in delivery of multiple copies of the message, since it has
  been successfully sent and the server has accepted responsibility for
  delivery.  See Section 6.1 for additional discussion.
4.5.3.2.7.  Server Timeout: 5 Minutes.
  An SMTP server SHOULD have a timeout of at least 5 minutes while it
  is awaiting the next command from the sender.

The most common problem we see with email marketers is that their mail servers fail to wait at least three minutes for each DATA send operation to complete. Probably the second most common problem is senders who seem to set an arbitrary timeout on the delivery of the entire message.
